2003 CURIONI SUN MASTER 541 (gearless) square bottom paper bag machine with twisted handles unit
2003 CURIONI SUN MASTER 541 (gearless) square bottom paper bag machine with twisted handles unit
Posizione:
Disponibilità in magazzino:1
Descrizione
The paper bag making machine SUN MASTER 541 is fed by reel,completely realized with GEARLESS TECHNOLOGY, and it has been designed to manufacture square bottom paper bags with or without handles, from the mediuml up to the big formats.
This pre-owned CURIONI SUN MASTER 541 of the year 2003, is equipped with twisted handle making unit for the manufacture and application of handles which is in line with the paper bag making machine (international Patent).
Machine immediately, visible in production and available subject to unsold.
Specifiche
| Produttore | CURIONI |
| Modello | SUN MASTER 541 (gearless) square bottom paper bag machine with twisted handles unit |
| Anno | 2003 |
| Condizione | Used (visible in production) |
| Type | Reel fed square bottom paper bag making machines with twistedhandles unit |
| Bag width (min - max) | 220 – 540 mm |
| Bag length (min-max) | 270 - 650 |
| Bottom width (min-max) | 70 - 200 mm |
| Cut length (min-max) | 350 - 780 mm |
| Reel width (min - max) | 610 - 1430 |
| Max. diameter of the reel | 1500 mm |
| Inner core diameter | 76 mm |
| Mechanical speed | 200 cycles/minute (Production speed depends on paper quality, bag sizes, applications, etc.) |
| Handle unit (twisted) | Type of handles: Twisted handles | Twisted paper cord diameter mm 4 - 5 | Handle width mm 100 |Patch height mm 50 (1.96”) Patch length mm 200 (7.87”) Reels width mm 100 (3.94”) Max. diameter of paper reels for patches mm1050 | Inner core diameter mm 76 | Weight of usable paper for patches 90 -130 gsm |
| Total installed electrical power | 47 Kw |
| Dimensions of the machine (approx) | Length 15650 mm | Width 2930 mm | Height 2445 mm |
| Total gross weight (approx) | 22000 Kg |
| Compressed air supply | 600/700 kPa, dry and clean |
| Compressed air consumption | 100 Nl/min |
| Power supply | three-phase 400 V + NEUTRE + GROUND at 50 Hz + 5% |
| Visible in operation | yes |
