1999 WINDMÖLLER & HÖLSCHER (W&H) Astraflex 1570 mm
1999 WINDMÖLLER & HÖLSCHER (W&H) Astraflex 1570 mm
Location:Europe
orCall +39 346 4948054
Description
Pre owned C.I Flexo W&H Astraflex available for sale.
This press can print, from reel to reel, paper from 20 to 150 g/m2. The max width of the reels is 1670 mm and the max print width is 1570 mm.
The rewinder and unwinder can manage reels with diameters up to 1300 mm.
The machine is visible in operation, can be reserved and will be available for dismantling/delivery in May 2025.
Specifications
| Manufacturer | WINDMÖLLER & HÖLSCHER (W&H) |
| Model | Astraflex |
| Year | 1999 |
| Condition | Used (visible in production) |
| Max. print width | 1570 mm |
| Max web width/material passage | 1670 mm |
| Printing repeat (min. - max.) | 400 - 1200 mm |
| Max. unwinder reel diameter | 1300 mm |
| Max. rewinder reel diameter | 1300 mm |
| Inner core diameter | 76 mm |
| Material | Paper from 30 to 150 g/m2 |
| Max. mechanical speed | 365 m/min |
| Needed space | Lenght 22,7 m | width 7,8 m | heght 5,7 m |
| Additional information | Retrofit Berger phase 5 instead of Berger phase 3 with electrical and mechanical overhaul of the color groups performed in 2017 |
| Accessories | SLEEVES: tot. 367 pcs | GEARS: tot. 299 pcs | ANILOX: tot. 20 pcs | STEEL MANDRELS FOR MOUNTING SLEEVES: tot. 64 pcs | SHAFTS: tot. 13 pcs | INK COLLECTION PANS: tot. 16 pcs | DOCTOR BLADE CHAMBERS: tot. 13 pcs | INKWELLS: tot. 13 pcs | INK PUMPS: tot. 6 pcs | INKWELLS: tot. 13 pcs | SLEEVES TROLLEY: tot. 9 pcs | ANILOX TROLLEY: tot. 2 pcs |
